MAXHUB U4 Series 86" 4K Interactive Display, 16GB / 256GB
SKU U8640
86" 4K interactive flat panel with infrared 50-point touch, 16GB RAM, 256GB storage, Android 15, 500 nits, AI NPU.
- Screen size
- 86"
- Resolution
- 4K UHD
- Touch
- 50 points
- System
- Android 15
Pricing
Price on request in OMR
Written quote usually within one business day
Download datasheet (PDF)
-
Written quotation in OMR
Pricing, availability and warranty on one document.
-
Manufacturer warranty
Terms confirmed on your quotation.
-
All 11 governorates
Delivered from Muscat to Dhofar.
-
Quotations in Arabic & English
Ask for Arabic, English or both.
The product, in detail.
Screen and picture
- Screen Size
- 86"
- Resolution
- 3840 × 2160 (4K UHD)
- Display Color
- 10-bit (1.07 billion colours)
- Brightness
- 500 cd/m²
Touch and writing
- Touch Points
- 50 points
- Touch Technology
- Infrared
- Touch Accuracy
- ±0.5 mm
Built-in system
- Operating System
- Android 15
- Processor
- ARM 4× Cortex-A76 + 4× Cortex-A55, 2.4 GHz
- GPU
- Arm Mali-G610 MP4
- RAM
- 16 GB
Description
The MAXHUB U4 Series 86" is a premium 4K UHD interactive panel with Cortex-A76/A55 Octa-Core (2.4GHz), 16GB RAM, 256GB storage, and Android 15. At 500 nits brightness with 10-bit color, 50-point infrared touch (±0.5mm accuracy, <10ms response), and pen/touch differentiation with palm rejection, it supports advanced annotation for enterprise collaboration. The 6 TOPS AI NPU accelerates real-time object detection and document scanning.
Connectivity includes 4× HDMI in, DisplayPort 1.2, dual RJ45 (in/out), 2× USB-C (65W/100W), 4× USB 3.0, TF card, and RS232. The 8-mic 12m array with multi-way stereo speakers (8W+8W+12W+12W+25W+25W) enables immersive conferencing. Blue light filter, non-glare etched-AG glass, and 800×600mm VESA mount support extended collaboration sessions.
Ideal for: Executive board rooms, training academies, multimedia labs, and premium corporate collaboration requiring enterprise-grade performance and AI features.
- 86" 4K UHD, 500 nits, 10-bit color, 60Hz refresh
- 50-point infrared touch, ±0.5mm accuracy, <10ms response
- Pen/touch differentiation, palm rejection, blue light filter
- Cortex-A76/A55, 16GB RAM, 256GB storage, 6 TOPS AI NPU
- 4× HDMI + DisplayPort 1.2, dual Gigabit (in/out), USB-C dual power
- 8-mic 12m array, multi-way speakers, Android 15
Specifications
Manufacturer specifications · confirmed on your quotation
Display
- Screen Size
- 86"
- Resolution
- 3840 × 2160 (4K UHD)
- Display Color
- 10-bit (1.07 billion colours)
- Brightness
- 500 cd/m²
- Backlight
- DLED
- Refresh Rate
- 60 Hz
- Viewing Angle
- 178° (H) / 178° (V)
- Blue Light Filter
- Yes
- Surface Protection
- Anti-glare (etched), 25% haze
Touch
- Touch Technology
- Infrared
- Touch Points
- 50 Points Multi Touch
- Touch Accuracy
- ±0.5 mm
System
- Operating System
- Android 15
- Processor
- ARM 4× Cortex-A76 + 4× Cortex-A55, 2.4 GHz
- GPU
- Arm Mali-G610 MP4
- RAM
- 16 GB
- Storage
- 256 GB
- OPS slot
- Yes (module slot)
Connectivity
- HDMI Input
- HDMI In × 4
- HDMI Output
- HDMI Out × 1
- DisplayPort
- DisplayPort In × 1
- USB-C input
- USB-C × 2
- USB Ports
- USB 2.0 × 1, USB 3.0 × 4
- Touch USB ports
- Touch USB × 2
- Audio in
- Audio in × 1
- Audio out
- Audio out × 1
- Ethernet
- RJ45 IN × 1, RJ45 OUT × 1
- Wi-Fi
- Wi-Fi 6 (802.11ax), 2.4/5 GHz
- Bluetooth
- Bluetooth 5.2
- Serial Port
- RS-232 × 1
- SD card slot
- microSD card slot × 1
Camera & audio
- Camera
- 50 MP
- Built In Microphone
- 8-mic array, 12 m pickup range
- Microphone Range
- 12 m
- Speaker Type
- Built-in Speakers
- Speaker Output
- 2 × 8W + 2 × 18W (output); 2 × 12W + 2 × 25W (maximum)
Physical & warranty
- Power Consumption
- 100 W
- Power Standby
- 0.5 W
Other
- Key Features
- Palm rejection, Pen and touch differentiation
- Package Contents
- Smart Pen: SP30B, Sensor Box: WL10C, WL20, Mobile Stand: ST33M, ST23B, EST09
- Accessories
- Smart Pen: SP30B, Sensor Box: WL10C, WL20, Mobile Stand: ST33M, ST23B, EST09
