BenQ
BenQ Board Master RM04 86" 4K Interactive Display
SKU RM8604
86-inch 4K interactive display with 40-point infrared touch, Android 13, 8GB RAM, 64/128GB storage options.
- Screen size
- 86"
- Resolution
- 4K UHD
- Touch
- 40 points
- System
- Android 13
Pricing
Price on request in OMR
Written quote usually within one business day
Download datasheet (PDF)
-
Written quotation in OMR
Pricing, availability and warranty on one document.
-
Manufacturer warranty
Terms confirmed on your quotation.
-
All 11 governorates
Delivered from Muscat to Dhofar.
-
Quotations in Arabic & English
Ask for Arabic, English or both.
The product, in detail.
Screen and picture
- Screen Size
- 86"
- Resolution
- UHD 3840 × 2160 pixels
- Display Color
- 10-bit
- Brightness
- 450 cd/m²
Touch and writing
- Touch Points
- up to 40
- Touch Technology
- High Precision IR
- Touch Response Time
- < 5 ms
Built-in system
- Operating System
- Android 13
- Processor
- Arm Cortex-A73 × 4 + A53 × 4
- GPU
- Arm Mali-G52 MP8
Description
The BenQ Board Master RM04 86-inch model is a premium interactive display for corporate board rooms and university lecture theaters. The 86-inch 4K UHD panel reaches 450 cd/m² brightness with 178° viewing angles, delivering cinema-grade visuals for audiences of 50+ people. Powered by Arm Cortex A73 × 4 + A53 × 4 processor with Mali-G52 MP8 GPU, 8GB RAM, and 64GB or 128GB storage running Android 13, it handles 4K video playback and complex collaborative applications.
Infrared 40-point touch with <8 ms response enables simultaneous multi-user interaction. Four HDMI 2.0 inputs and one HDMI output, plus DisplayPort 1.2a and VGA input, support professional source flexibility. Dual Gigabit Ethernet (one Data, one for optional PoE), USB-C (65W PD), and extensive USB 3.0 and USB 2.0 ports enable rich peripheral connectivity including NFC card reader for attendance tracking and interactive quizzes. Built-in 20W × 2 speakers and ambient light sensor provide smart brightness adjustment and immersive audio. Three touch-USB 3.0 output ports support edge-connect peripherals and interactive accessories.
Ideal for: Corporate boardrooms, government meeting centers, university lecture halls, and executive training facilities in Oman requiring enterprise-grade 86-inch displays with comprehensive connectivity and ambient sensing.
- Screen: 86" diagonal, 4K UHD (3840×2160), 178° viewing angle
- OS: Android 13 with enterprise collaboration features
- Processor: Arm Cortex A73 ×4 + A53 ×4 with Mali-G52 MP8 GPU
- Memory: 8GB RAM, 64GB or 128GB storage options
- Touch: 40-point infrared, <8 ms response, NFC card reader
- Brightness: 450 cd/m² with D-LED backlight
- Video Inputs: HDMI In ×3 (HDMI 2.0), HDMI Out ×1, DisplayPort 1.2a ×1, VGA ×1
- Connectivity: Dual Gigabit Ethernet, USB-C (65W PD), 5× USB 3.0, 2× USB 2.0
Specifications
Manufacturer specifications · confirmed on your quotation
Display
- Screen Size
- 86"
- Resolution
- UHD 3840 × 2160 pixels
- Display Color
- 10-bit
- Brightness
- 450 cd/m²
- Backlight
- D-LED
- Refresh Rate
- 60 Hz
- Viewing Angle
- 178° (H) / 178° (V)
- Blue Light Filter
- Yes
- Surface Protection
- 9H tempered
Touch
- Touch Technology
- High Precision IR
- Touch Points
- up to 40
- Touch Response Time
- < 5 ms
System
- Operating System
- Android 13
- Processor
- Arm Cortex-A73 × 4 + A53 × 4
- GPU
- Arm Mali-G52 MP8
Connectivity
- HDMI Input
- HDMI In (HDMI 2.0) × 3
- HDMI Output
- HDMI Out × 1
- DisplayPort
- 1 × 1.2a
- USB-C input
- 1 × 3.0 (PD 65 W), 2 × 3.0
- USB Ports
- USB 3.0 × 5, USB 2.0 × 2
- Touch USB ports
- 3 × 3.0
- Audio in
- Mic × 1
- Audio out
- Earphone × 1
- Ethernet
- RJ45 (1000 Mbps Port) × 1
- Wi-Fi
- Wi-Fi 6 (optional)
- Bluetooth
- Bluetooth 5.2
Camera & audio
- Built In Microphone
- 8-microphone array (range: up to 8 m | 26ft)
- Speaker Type
- Built-in Speakers
- Speaker Output
- 2 × 20 W (max)
Physical & warranty
- Dimensions
- 1962.4 × 1174.9 × 87.1 mm (77.3 × 46.3 × 3.4 inch)
- Weight
- 65.2 kg
- Shipping Dimensions
- 2095.0 × 1265.0 × 185.0 mm (82.5 × 49.8 × 7.3 inch)
- VESA
- VESA 800 × 600 mm ( 4 × M8 × 25L)
- Mounting Orientation
- Landscape
- Wall Mount
- 800 × 600 mm (VESA)
- Power Consumption
- 168.9 W
- Power Standby
- <0.5 W
- Operating Temperature
- 0°C ~ 40°C | 32°F ~ 104°F
- Operating Humidity
- 20% ~ 80% RH non-condensing
Other
- Package Contents
- 1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
